Cressi AC5 Zen Regulator

Original price was: $629.00.Current price is: $511.20. inc. GST

Cressi AC5 Zen Regulator. Simple piston first stage with the compact Zen for warm-water diving.

Colour: Black / Red

Type

Clear

Cressi AC5 Zen Regulator

The AC5 and Zen pair a straightforward piston first stage with Cressi’s compact Zen second stage. Designed for warm-water diving, the combination suits divers who want simple controls and a low-bulk recreational regulator.

Features and benefits

Straightforward first stage. Unbalanced piston uses a conventional mechanism in the listed regulator configuration.
Venturi control. Select the appropriate setting for surface handling or diving to help manage free-flow tendency.
Connection options. 1 × 7/16 in UNF HP ports and 4 × 3/8 in UNF LP ports support the stated gauge and hose configuration.

Setup and compatibility

Connection: DIN, Yoke. Choose the fitting that matches your cylinder valve and its pressure rating. Intended for warm-water use above 10°C. The AC5 and Zen configuration includes the primary first and second stages; an octopus is purchased separately.

Technical Specs

Cressi AC5 Zen Regulator technical specifications
Brand	Cressi
Main model / configuration	Cressi AC5 / Zen
Product type	Regulator
Regulator type	Primary Regulator
Regulator connection	Din, Yoke
First-stage design	Unbalanced piston
Second-stage design	Standard downstream
High-pressure ports	1 × 7/16 in UNF
Low / medium-pressure ports	4 × 3/8 in UNF
Cold-water suitability	Warm water above 10°C
Breathing adjustment	Venturi adjustment
Intermediate pressure	9.5–10 bar
Regulator set weight	Not confirmed — contact us for the weight of your exact configuration.
First-stage weight	DIN: 435 g; INT/yoke: 600 g
Second-stage weight	149 g without hose
Connection pressure rating	DIN 232 bar; INT/yoke 232 bar

Additional specifications

2nd stage weight (without hose)	149 g

Unique to Cressi is the AC5’s external 1st stage IP adjustment system. This allows service centres to fine-tune the intermediate pressure while the regulator is attached to the cylinder, providing a quick fix to keep it in use until the next service interval. The high-capacity conical filter, which offers a larger surface area than traditional flat filters, traps impurities before they damage the internal components of the 1st stage.
Balanced Diaphragm First Stage For Reliable Performance
Optimized Airflow For Effortless Breathing At Any Depth
Adjustable Venturi Effect For Personalized Breathing Resistance
Certification EN 250/2014 A over 10°
EN 250 A > 10°C
The unbalanced piston 1st stage is simple, dependable and easy to maintain.
1 7/16” HP ports UNF
4 3/8” LP ports UNF
Adjustable venturi maximises airflow in dive mode and prevents free-flows when the regulator is on the surface.
Large purge button is easy for new divers to use.

Based on Cressi product information.
