Cressi Mini Pressure Gauge (SPG) Console
The Cressi mini pressure gauge is a compact and lightweight instrument designed to minimise strain on the HP hose connecting to the regulator’s first stage.
Constructed from chromium-plated brass, the instrument boasts exceptional strength.
The front glass serves as a pressure relief valve, rising slightly in response to sudden pressure increases, allowing excess pressure to escape.
The luminescent dial is calibrated to 350 BAR in the metric version and 5000 PSI in the imperial one.
The scale is divided into three colour-coded zones: red for pressures below 50 BAR, green for pressures between 50 and 200 BAR, and light blue for pressures above 200 BAR.
The gauge is housed in a compact, modern console made from polycarbonate and desmopan, two lightweight materials that provide shock and scratch protection. A loop in the upper protective shell allows for quick attachment to the jacket, preventing accidental damage to the environment.
Cressi Mini Pressure Gauge Features:
- Gauge dial is colour-coded in red, yellow and green for instant readability.
- Reads pressures to 350 bar
- Rugged mini-gauge has a chrome-plated brass case.
- Compact rubber boot is textured for a sure grip.
- Connection loop up-top is perfect for attaching a clip or bungee.
- Instrument diameter: 50 mm
- Height of case: 14 mm
- Total instrument height: 17 mm
- Hose diameter: 11 mm
